DOGFS-4.5WIRE-50
A DIY Dog Fence so versatile, it can be installed nearly anywhere you need a safe and strong dog-proof barrier that doesn’t block your view.
Need a fence to stop your dog from roaming into your neighbor’s yard or running away? Create a dog-safe enclosure to any size you’d like. Don’t want your dog to have access to the entire yard? Build a partition that gives your dog their own space. Want to keep your dog out of the pool or your bountiful vegetable garden? Put up a Freestanding Dog Fence around the area to keep it dog-free!
No matter how you choose to use the Dog Proofer DIY Freestanding Dog Fence System, rest assured that it can easily be reconfigured or expanded as your needs change. A reliable permanent fence for the life of your dog. At the same time also can be a great temporary dog fence solution for renters - The fence can even be relocated when you move into a new home!
All of the metal components are made of galvanized steel for time-tested, long-lasting use outdoors. For added protection against every day wear and tear, posts are also powder-coated black. Our 6' and 7' tall versions utilize heavy-duty 1 5/8” diameter posts to stand up to even the strongest of dogs. Our 4.5’ tall version for small to medium dogs uses standard 1 3/8” diameter steel posts for ease of installation.
Designed specifically for use with pets, our welded wire mesh fencing material is rigid, durable, and strong against impacts. With a breaking strength of over 1000 lbs, the DIY Freestanding Dog Fence System provides a secure barrier for dogs of all sizes.
Square openings measure 1.7” x 1.7” which allows for the least obstructed view that your dog cannot scratch, chew, or fit through. Our heavy-duty welded wire mesh is made of galvanized steel wire with a black vinyl coating that allows it to virtually disappear in the distance.
For reference, the wire strands of the welded wire mesh have a diameter of about 2.2-2.4mm.
Worried that your dog might dig their way out underneath the fence? We’ve got you covered!
A welded wire bottom barrier is included with every DIY Freestanding Dog Fence. This creates a physical barrier on the ground leading up to your fence. The wire mesh dig-proof barrier is secured in place to the ground with easy-to-install galvanized ground stakes. The openings in the mesh allow grass to grow up through the barrier, making it nearly invisible after installation!
Dog Proofer fence extension solutions are extremely versatile so they can be installed on an existing fence or wall of nearly any type for dogs that jump or climb over traditional fencing. They can even be used alongside our Freestanding DIY Dog Fence to secure unfenced areas. Give your dog a safe and secure enclosure for the peace of mind you deserve. Read more about how you can combine Dog Proofer systems to create a safe outdoor space for your dog, HERE.
Expect a straightforward installation with our unique ground-driven galvanized steel sleeves. No back-breaking post holes need to be dug and concrete is not required for installation. The Dog Proofer DIY Freestanding Dog Fence is intended to be installed by the homeowner, so no specialized tools are needed.
It is not generally considered difficult to complete installation for anyone that considers themselves to be handy (site dependent). If it is something you prefer not to do yourself we would recommend using a local well-regarded handyman. Most fences can be installed in a weekend (or less) and be put to use immediately after completion!
Although our systems are designed to be simple to plan and easy to install, we are available to answer any questions you may have regarding your layout or installation. We can talk or email you, or your chosen handyman, through almost any unforeseen obstacles you may run into during installation: contact us for more information!
If access is required through the Freestanding Dog Fence, consider adding a gate to your layout. Gates are offered specifically to the version/height of the fencing selected. Be sure to select the correct gate that matches the height/version of your chosen dog fence system. For example, a 4.5 ft height gate is not compatible with a 6 ft height dog fence system.
The height of our heavy-duty gate is available to match the version of the freestanding dog fence purchased:
Each gate version is available in 36" Width or 60" Width.
⚠ If the pet you are seeking to safely contain has a history of aggressive chewing or destructive incidents with rugged materials please contact our planning experts prior to placing your order so we can discuss special considerations. Your satisfaction and your dog(s) safety is our number one priority.
Kit sizes are provided in linear feet of fencing. For example, a 100-foot kit will include the materials and components needed to create up to 100 linear feet of Freestanding Fence, so long as no special circumstances or obstacles exist that may require additional components.
A 100-foot kit made into a square would be approximately 24' x 24' (576 square feet) but most customers use the back of their house as a "side" which allows a kit to make a larger overall enclosure and provides easier access for dogs. One example that uses a 100-foot kit off the back of a house would be 27' x 45' (27' out from the house - over 45' and back 27') making an enclosure that is 1,215 square feet. A 200-ft kit off the back of a house could be 63' x 63' (63' out from the house - over 63' and back 63') making an enclosure that is 3,969 square feet.
Keep in mind a Zip Tie Puller/Cutter tool is included with your purchase of a Freestanding Dog Fence System.
If you are unsure about the appropriate kit size or number of components for your project, we suggest reaching out to our expert planning team for assistance!
| Freestanding DIY Dog Fence (4.5ft Tall) | 50 Foot Kit | 100 Foot Kit | 150 Foot Kit | 200 Foot Kit | 250 Foot Kit | 300 Foot Kit | 350 Foot Kit | 400 Foot Kit | 450 Foot Kit | 500 Foot Kit |
|---|---|---|---|---|---|---|---|---|---|---|
| 68" Posts | 6 | 12 | 18 | 24 | 30 | 36 | 42 | 48 | 54 | 60 |
| Post Caps | 6 | 12 | 18 | 24 | 30 | 36 | 42 | 48 | 54 | 60 |
| 24" Ground Sleeves | 6 | 12 | 18 | 24 | 30 | 36 | 42 | 48 | 54 | 60 |
| Driving Cap | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Self Tapping Screws | 12 | 24 | 36 | 48 | 60 | 72 | 84 | 96 | 108 | 120 |
| Driver Bit for Self-Taps | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Zip Tie Puller/Cutter | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| S Hooks | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 |
| 42" Coated Wire | 50 Feet | 100 Feet | 150 Feet | 200 Feet | 250 Feet | 300 Feet | 350 Feet | 400 Feet | 450 Feet | 500 Feet |
| 24" Coated Wire | 50 Feet | 100 Feet | 150 Feet | 200 Feet | 250 Feet | 300 Feet | 350 Feet | 400 Feet | 450 Feet | 500 Feet |
| 12" Galvanized Ground Stakes | 30 | 60 | 90 | 120 | 150 | 180 | 210 | 240 | 270 | 300 |
| UV Rated Light Ties (bags) | 2 | 4 | 6 | 8 | 10 | 12 | 14 | 16 | 18 | 20 |
| UV Rated Heavy Ties (bags) | 1 | 1 | 2 | 2 | 3 | 3 | 3 | 4 | 5 | 5 |
| Post to Wall/Structure Hardware* | 2 Sets | 2 Sets | 2 Sets | 2 Sets | 4 Sets | 4 Sets | 4 Sets | 4 Sets | 4 Sets | 4 Sets |
| Written Installation Instructions | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| *Fasteners Not Included |
| Freestanding DIY Dog Fence (6' Tall) | 50 Foot Kit | 100 Foot Kit | 150 Foot Kit | 200 Foot Kit | 250 Foot Kit | 300 Foot Kit | 350 Foot Kit | 400 Foot Kit | 450 Foot Kit | 500 Foot Kit |
|---|---|---|---|---|---|---|---|---|---|---|
| 86" Posts | 6 | 12 | 18 | 24 | 30 | 36 | 42 | 48 | 54 | 60 |
| Post Caps | 6 | 12 | 18 | 24 | 30 | 36 | 42 | 48 | 54 | 60 |
| 30" Ground Sleeves | 6 | 12 | 18 | 24 | 30 | 36 | 42 | 48 | 54 | 60 |
| Driving Cap | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Self Tapping Screws | 12 | 24 | 36 | 48 | 60 | 72 | 84 | 96 | 108 | 120 |
| Driver Bit for Self-Taps | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Zip Tie Puller/Cutter | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| S Hooks | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 |
| 42" Coated Wire | 100 Feet | 200 Feet | 300 Feet | 400 Feet | 500 Feet | 600 Feet | 700 Feet | 800 Feet | 900 Feet | 1000 Feet |
| 12" Galvanized Ground Stakes | 30 | 60 | 90 | 120 | 150 | 180 | 210 | 240 | 270 | 300 |
| UV Rated Light Ties (bags) | 2 | 4 | 6 | 8 | 10 | 12 | 14 | 16 | 18 | 20 |
| UV Rated Heavy Ties (bags) | 1 | 2 | 2 | 2 | 3 | 3 | 3 | 4 | 4 | 5 |
| Post to Wall/Structure Hardware* | 2 Sets | 2 Sets | 2 Sets | 2 Sets | 4 Sets | 4 Sets | 4 Sets | 4 Sets | 4 Sets | 4 Sets |
| Written Installation Instructions | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| *Fasteners Not Included | ||||||||||
| Freestanding DIY Dog Fence | 50 Foot Kit | 100 Foot Kit | 150 Foot Kit | 200 Foot Kit | 250 Foot Kit | 300 Foot Kit | 350 Foot Kit | 400 Foot Kit | 450 Foot Kit | 500 Foot Kit |
|---|---|---|---|---|---|---|---|---|---|---|
| 7' Tall with Escape-Proof Top | ||||||||||
| 86" Posts | 6 | 12 | 18 | 24 | 30 | 36 | 42 | 48 | 54 | 60 |
| Post Caps | 6 | 12 | 18 | 24 | 30 | 36 | 42 | 48 | 54 | 60 |
| 30" Ground Sleeves | 6 | 12 | 18 | 24 | 30 | 36 | 42 | 48 | 54 | 60 |
| Houdini-Proof Extensions | 6 | 12 | 18 | 24 | 30 | 36 | 42 | 48 | 54 | 60 |
| Set Screws | 18 | 36 | 54 | 72 | 90 | 108 | 126 | 144 | 162 | 180 |
| Self Tapping Screws | 12 | 24 | 36 | 48 | 60 | 72 | 84 | 96 | 108 | 120 |
| Driving Cap | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Driver Bit for Self-Taps | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Hex Wrench | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Zip Tie Puller/Cutter | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| S Hooks | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 |
| 42" Coated Wire | 100 Feet | 200 Feet | 300 Feet | 400 Feet | 500 Feet | 600 Feet | 700 Feet | 800 Feet | 900 Feet | 1000 Feet |
| 24" Coated Wire | 50 Feet | 100 Feet | 150 Feet | 200 Feet | 250 Feet | 300 Feet | 350 Feet | 400 Feet | 450 Feet | 500 Feet |
| 12" Galvanized Ground Stakes | 30 | 60 | 90 | 120 | 150 | 180 | 210 | 240 | 270 | 300 |
| UV Rated Light Ties (bags) | 4 | 8 | 12 | 16 | 20 | 24 | 28 | 32 | 36 | 40 |
| UV Rated Heavy Ties (bags) | 1 | 2 | 3 | 4 | 4 | 5 | 6 | 7 | 8 | 8 |
| Post to Wall/Structure Hardware* | 2 Sets | 2 Sets | 2 Sets | 2 Sets | 4 Sets | 4 Sets | 4 Sets | 4 Sets | 4 Sets | 4 Sets |
| Written Installation Instructions | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| *Fasteners Not Included |
Please reference "Kit Sizing" for the total number of posts included with each kit.
If your layout includes multiple turns or very specific side lengths, you may need additional posts above and beyond what is provided in the kits. To determine the total number of posts needed or your layout, use these guidelines:
If additional posts are needed, they are available for purchase and can be added to your kit.
For ease of installation and delivery, the wire mesh is split into 2 separate parts. There is an upper portion and lower portion with overlap along the middle. This overlap creates additional strength then the overlap is secured together permanently during installation to create one seamless barrier.
Welded wire mesh is secured to posts with our black UV stable 120lb test Heavy Duty Zip Ties.
Fasteners for holding hardware to buildings/structures are not included. Fasteners should be chosen based on the type of material covering the building/structure (wood screw, masonry screw, etc.).
Included: These tools are included with your kit
Required, Not Included: These tools are required to install this product
Optional: These tools will speed up & simplify the installation. We offer these items sold separately.
One of the best aspects of our system is its flexibility. You can essentially place your fence line as you see fit in terms of shape, dimensions, gate placements, etc.
Below are several common sample layouts that may be exactly what you had in mind or perhaps just inspire you to design your own layout that will perfectly suit your needs. If you need help with this, please contact us! Our team of experts are available to help with everything from simple questions to full layout and quoting assistance as needed.
I installed 200’ of fence with 3 gates. Only problem I found was I’m 58 and way out of shape to swing a sledge hammer. So it took me longer than I thought to install the sleeves. I did purchase a 12 lb dead blow that made things a lot easier. Once I installed all the post and built and installed the gates putting the fence up was really easy and I did it all myself!
I really recommend this system you won’t regret it!
The only thing I would say that is negative is I wish the gates were the same height on the 4.5ft fence
Love it. Dogs have not escaped. Works great!
The only complaint i have is that the gate did not come with the necessary screws to put together the gate frame. I had to go out and buy them myself to complete the gate.
Hello Danny, thank you for sharing your experience. All of our gates come with the proper screws for installation. If you did not receive these components, this could have been an accidental mispack from our fabrication team in Michigan. Please contact our support team and we can get these delivered to you immediately. Thanks!
I ordered and have now installed 200 feet of the 4.5 fencing and so far our dogs have been unable to violate the enclosure, not for lack of trying. Very sturdy and not visually obtrusive solution to our needs.
Having done the install myself, I can say that it is labor intensive and some parts of it are quite tedious. Using the iron cap and driving in the stakes was a piece of cake in my yard, which was rock free; I wouldn’t expect it to be a breeze otherwise. The poles and the first, upper piece of fencing went in easily, but the second, lower row has to be bent at the bottom and attached with 100s of zip ties — the tedious part! Some tips for potential self-installers:
1. Instructions don’t say so, but install the first, upper fencing inside the enclosure. Then it will match up with second, lower fencing, which has to be put inside to prevent escape digging. (I didn’t do this, so the two pieces are on opposite sides of every pole.)
2. At corners, and whenever there’s a grade change, cut the fencing at a pole. Instructions are vague on this point. Much easier, it turns out, to attach lots of short pieces than one long segment of fence, and fewer sags that way.
3. Instructions say to hand tighten smaller zip ties when attaching the two fences; my fingers couldn’t handle this. I used the tool included for the big ties, gently tightening up and cutting off the excess in one motion.
In short, one star off for lack of full instructions and/or a full-on official online video of how to do the install correctly.
The fence went up very easy have two gates put in holds are German shepherds in the yard works great great product thanks
Installed 90ft of 4.5 ft tall fencing and one gate. Every component is solidly constructed and the installation plan is well thought out. The most difficult part of the installation is getting the post holders in the ground. But then it depends on your soil. I’m in Georgia with lots of red clay. I was able to put the entire thing up and I’m 65 years old. This fence is meant to contain a 90 lb German Shepherd and 70 lb Doberman. It’s doing its job. The one component I would like to see revised is the S hooks for holding the fence sections in place while you install them. They are on the light side. I would like to see larger and more substantial S hooks. One thing I would suggest during installation is to take the time to lay the sections out flat and get the bend out of them before installing. The fencing comes in rolls so it is naturally going to have some bend in it. Overall I am extremely satisfied with this product.
